SCAN3D scanning and dimensional capture
Capture geometry, mounting interfaces and surrounding constraints.
SPECIALIST MARINE SOLUTION
3D Engineering & Custom Technical Solutions
Reverse engineering and production-ready solutions for unavailable parts.
CaptureGeometry, interfaces and installation constraints
DevelopCAD, prototypes and controlled revisions
ReleaseDrawings and production-ready files
ENGINEERING CAPABILITIES
From physical problem to production-ready solution.
Explore the approved 3D engineering, reverse-engineering and custom-design services available for unusual or unavailable components.
SCAN
REReverse engineering of unavailable components
Rebuild unavailable parts from measurements and functional evidence.
CADCAD modeling and design development
Develop controlled geometry, features and design revisions.
2DTechnical drawings and manufacturing files
Prepare dimensions, tolerances, material notes and manufacturing data.
FITFunctional prototypes and fit-testing
Validate fit, access and function before final manufacture.
3DP3D-printed replacement parts
Produce suitable prototypes and approved noncritical replacement parts.
CUSTOMCustom brackets, covers, adapters and enclosures
Design purpose-built brackets, covers, adapters and enclosures.
LAYOUTEquipment-layout and installation planning
Review clearances, routing, access and installation sequence digitally.
ASMSmall mechanical assemblies and design improvements
Refine small assemblies for fit, reliability and serviceability.
ONE-OFFOne-off technical solutions for unusual onboard problems
Solve unusual onboard constraints through staged design and validation.
INTERACTIVE DESIGN VALIDATION
Test the fit before committing to manufacture.
Move through the engineering stages, rotate the bracket and introduce a mounting deviation to see how the design responds before release.
Preparing the 3D model…
SERVICES WE PROVIDE
From capture to production-ready delivery.
Each project is scoped around function, interfaces, material, accuracy and the intended manufacturing route.
Component capture and measurement
Capture the original component, its interfaces and operating requirement.
Reverse engineering
Reconstruct controlled CAD geometry for unavailable or damaged parts.
Custom mechanical design
Design practical components and assemblies around the confirmed installation.
Prototype and fit validation
Prototype, trial-fit and revise before committing to final manufacture.
Production-ready documentation
Release clear drawings and files suitable for the agreed production method.
Complete custom solution
Coordinate the complete route from problem definition to verified fit.
CONTROLLED DESIGN ROUTE
A clearer path from scan to installed fit.
Each stage reduces uncertainty before material and production cost are committed.
Capture
Measure the part, interfaces and installation space.
Model
Build controlled CAD geometry and define design intent.
Validate
Check fit, access and function with a prototype where required.
Release
Issue the approved manufacturing files and drawing package.
Design decisions follow the operating environment.
Mechanical loadTemperatureChemicalsFire requirementsSafety classification
COMMON ISSUES
Where custom engineering becomes useful.
Select situations that help define the technical starting point—not a guaranteed reproduction route.
Replacement part unavailable
Obsolete or unsupported components may be candidates for reverse engineering after function, material and risk are reviewed.
Request an inquiryPREPARE THE INQUIRY
Give the team useful evidence before the visit.
Provide photographs, approximate dimensions, the failed component, its function, installation location, mating parts, required quantity and any known material or load information.
Request an inquiry ↗obaida.ak@silentcoreindustries.comGuidance and image review are preliminary. Final diagnosis, price and recommendations may require physical inspection.
